Hard tooth surface reducers often have broken teeth, don't just blame the quality, it's all because the selection factor is too small and they stumble

In the practical application of hard tooth surface reducers, a small selection factor is indeed one of the core reasons for serious faults such as tooth breakage. Based on industrial practice and mechanical principles, the specific mechanisms and related factors behind this phenomenon can be analyzed in depth from the following aspects:

1. Misconceptions in selection and insufficient torque margin

Many users have a dangerous misconception when selecting, thinking that as long as the "rated output torque" of the gearbox meets the working requirements, it is sufficient. In fact, the correct engineering selection must have sufficient torque margin:

Theoretical calculation principle: The value obtained by multiplying the rated output torque of the motor by the reduction ratio should generally be smaller than the rated output torque provided by the gearbox sample. At the same time, the maximum working torque required by the user must be strictly less than twice the rated output torque of the gearbox.

Impact load and overload risk: If the selection is too small, the strong overload capacity of the motor will continue to increase the output when the equipment accelerates, decelerates, emergency stops, or the load suddenly freezes. The instantaneous dynamic torque generated at this time (which may easily exceed 2 to 3 times the rated torque) will cause the torque borne by the output shaft of the gearbox to instantly exceed the yield limit, ultimately leading to gear shear fracture or output shaft torsion fracture.

2. Special requirements for heavy-duty working conditions such as rolling mills

In heavy industries such as metallurgy and mining, the requirements for selection coefficients are more stringent due to the equipment being in low-speed, heavy load, high impact load, and frequent working conditions for a long time. For example, when purchasing a steel rolling reducer, the torque reserve coefficient for the roughing stage must be at least 1.5, and for the finishing stage it must be at least 1.2. If the reserve coefficient of impact resistance is too low, it is highly likely to cause gear failure or even tooth breakage.

3. The superposition effect of material strength and manufacturing defects

Although the small selection factor is the main reason, the tooth breakage of hard tooth surface reducers is often the result of multiple factors combined. If the material selection is improper or the manufacturing process is poor, it will further reduce the true load-bearing capacity of the gear:

Material and heat treatment issues: Some inferior products' gears are made of ordinary steel instead of high-strength alloy steel, or the control of heat treatment processes such as carburizing and quenching is not strict, resulting in insufficient surface hardness or uneven internal structure. This makes gears prone to fatigue cracking under alternating stress, and tooth breakage may occur within less than a year of use.

Design and processing defects: If the modulus is selected too small during design, it will lead to excessive bending stress at the tooth root; However, problems such as low machining accuracy and small fillet radius at the tooth root can cause serious stress concentration and become the starting point of fatigue cracks.

In summary, in order to avoid tooth breakage in hard tooth surface reducers, it is not only necessary to scientifically and rigorously evaluate the dynamic loads in actual working conditions and amplify the selection factor, but also to strictly control the material, heat treatment quality, and machining accuracy of the equipment.
