Three situations and prevention strategies of gear breakage in roller press reducer

1、 Three situations of gear breakage in roller press reducer

1. Fatigue induced tooth breakage

This is the most common form of fracture. Due to the repeated action of variable stress (alternating bending stress) on gear teeth over a long period of time, fatigue cracks occur at stress concentration sources such as root fillet and machining tool marks. As the crack gradually spreads and expands, it ultimately leads to fatigue fracture of the gear teeth.

2. Overload impact fracture

When the reducer encounters abnormal external forces or sudden increases in load during operation (such as equipment start-up, emergency stop, emergency braking), the impact force instantly exceeds the bending resistance limit of the gear teeth, which can cause the gear teeth to suddenly break without obvious early signs.

3. Foreign object jamming and fracture

When detached bearing balls, loose screws, large pieces of metal, or foreign objects accidentally fall into the gear meshing area, it can cause a significant increase in local stress, leading to gear tooth breakage.

2、 Comprehensive prevention and response strategies

In order to effectively prevent the crisis of tooth breakage and ensure the smooth operation of equipment, it is recommended to implement preventive measures from the following dimensions:

1. Optimize design and manufacturing processes

Strength verification: Reasonably design gear parameters, verify the bending strength of gears, and ensure that the bending strength safety factor (SF) is greater than 2.

Material and Heat Treatment: Adopting a reasonable gear blank heat treatment process, controlling material properties, ensuring that the tooth core material has sufficient toughness, and improving fatigue and impact resistance.

Root strengthening: making the transition curve of the tooth root smoother, eliminating machining tool marks to reduce stress concentration; The surface of the tooth root is strengthened using processes such as shot blasting and hydraulic treatment.

2. Improve equipment protection and buffering mechanisms

Overload protection: Install a hydraulic coupling or soft start safety coupling at the input shaft end of the reducer. In overload or stuck state, the coupling can limit power increase by slipping, effectively buffer and absorb vibration, and protect the reducer and motor.

Anti loosening measures: Reliable anti loosening measures must be taken for screws, bolts and other components that may fall off inside the reducer to prevent foreign objects from falling into the engagement area.
